Source Guitars: 16 Types
Sampling frequency: 44.1 kHz
A/D conversion: 24-bit with 128x oversampling
D/A conversion: 24-bit with 128x oversampling
Signal processing: 32-bit
Frequency characteristics: 20 – 20 kHz +1 dB, -3 dB (10 kΩ load)
Input: Standard monaural phone jack Rated input level: -20 dBu* Input impedance: 10 MΩ
1/Mono/Phones: Standard stereo phone jack (combined line/headphones)Maximum output level: Line +7 dBu* (10 kΩ or more) Stereo mini jack (3.5 mm) Headphones 8 mW + 8 mW (into 32 Ω load)
2: Standard mono phone jack Maximum output level: Line +7 dBu (10 kΩ or more output impedance)
Balanced Output: XLR jack Output impedance: 100 Ω (HOT-GND, COLD-GND), 200 Ω (HOT-COLD) PRE/POST (switchable) GND LIFT (switchable)
Additional Specifications
Equivalent input noise: 120 dBu*
Noise floor (residual noise): -100 dBu
Power: AC adapter DC9V, 500 mA center negative (ZOOM AD-16) Batteries: 2 AA (about 3 hrs continuous
USB: USB MIDI USB Micro-B
Dimensions: 158 mm (D) X 107 mm (W) X 52 mm (H)
Weight: 0.570kg / 1.26 lbs
