Width 153 cm (60 1/4")
Height 121 cm (47 3/4")
Depth 62 cm (24 1/2")
Weight 232 kg (511 lbs)
KEYBOARD
Key Surfaces - White Acrylic resin
Key Surfaces - Black Phenolic resin
Hammer U Series Special
Pedal Damper/Silencing pedal/Soft
Caster Double Caster
Lid Prop Safety Stop -
Lid/Fallboard Locks - Yes
Soft-Close Fallboard - Yes
Key Sensors Non-contact continuous detection optical sensor
PEDALS
Damper Pedal Continuous detection sensor
Sostenuto Pedal -
Soft/Shift Pedal On/Off detection sensor
Mechanism Hammer shank stopper operated by center pedal
Action -
TONE GENERATION
Piano Sound Yamaha CFX, Bösendorfer Imperial
Binaural Sampling Yes (CFX Grand Voice only)
VRM Yes
Key-off Samples Yes
Smooth Release Yes
Polyphony (max.) 256
Preset Number of Voices 20
Voices for Song Playback 480 XG Voices + 12 Drum/SFX Kits
Reverb Yes
Brilliance Yes
Stereophonic Optimizer Yes (Piano Voices other than CFX Grand)
SONGS
Number of Preset Songs 20 Voice Demo Songs, 50 Classics
Recording Number of Songs 10
Data Capacity approx. 550 KB
Playback Format WAV (44.1 kHz, 16 bit, stereo), SMF (Format 0, Format 1)
Recording Format WAV (44.1 kHz, 16 bit, stereo), SMF (Format 0)
Recording Time (max.) 80 minutes/Song
OVERALL CONTROLS
Metronome Yes
Tempo Range 5 – 500
Transpose -12 – 0 – +12
Tuning 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
