Control Interface
Number of keys: 88
Type: NW-GH (Natural Wood Graded Hammer) keyboard: synthetic ebony and ivory keytops
Voices
Tone Generating Technology: AWM2
Number of Polyphony (Max.): 128
Number of Voices: 57 (Piano: 10 / E. Piano: 14 / Sub: 33)
Effects
Delay: 2 types (Analog, Digital)
Reverb: 1 type (Hall)
Master EQ: 3 bands (with sweepable MID)
Insertion Effect: Piano: 2 systems (1: Damper Resonance / 2: Compressor, Distortion, Drive, Chorus), E. Piano: 3 systems (1: Drive / 2: Auto Pan, Tremolo, Ring Modulator, Touch Wah, Pedal Wah, Compressor / 3: Chorus1, Chorus2, Flanger, Phaser1, Phaser2, Phaser3), Sub: 1 system (Chorus/Flanger, Rotary Speaker, Tremolo, Distortion)
Connectivity
Line Out: OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED), OUTPUT [L]/[R] (XLR jacks, BALANCED)
Headphones: [PHONES] (6.3 mm, standard stereo phone jack)
Foot Controller: FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE]
MIDI: MIDI [IN]/[OUT]
USB: USB [TO HOST]/[TO DEVICE]
AUX: INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
Other
Connectors: [AC IN]
Display: Full Dot LCD (128 x 64 dots)
Additional package contents: Owner’s Manual x 1, Power cord x 1, Foot pedal (FC3A) x 1
Size/Weight
Width: 1,298 mm (51-1/8")
Height: 141 mm (5-9/16")
Depth: 364 mm (14-5/16")
Weight: 18.6 kg (41 lb, 0 oz)A
