INPUTS
INPUT 1: impedance 500 Kohm, max. voltage 15 Vpp
INPUT 2: (Balanced XLR/1/4″ combo)
BALANCED: impedance 500 Kohm, max. voltage 15 Vpp, phantom power 48V
EFFECT RETURN: impedance 33 Kohm, max. voltage 10 Vpp
CONTROLS
GAIN 1: -60 dB to +23 dB range
GAIN 2: -60 dB to +23 dB range
MIX: mixes tube and solid state gain
MASTER VOLUME
LINE OUT LEVEL
GROUND LIFT (switch on rear panel)
PRE/POST EQ (switch on rear panel)
MUTE (push/pull on master knob)
PHANTOM POWER switch (on INPUT 2 / Balanced)
EQUALIZATION
LOW: center frequency 40 Hz; level: ±16 dB
LOW MID: center frequency 360 Hz, level: ±16 dB
HIGH MID: center frequency 800 Hz, level: ±16 dB
HIGH: center frequency 10 kHz, level: ±16 dB
VPF (Variable Pre-shape Filter) center frequency 380 Hz
VLE (Vintage Loudspeaker Emulator) frequency range 250 Hz-20 kHz
OUTPUTS
LINE OUT: balanced XLR, max. voltage 20 Vpp
EFFECT SEND: unbalanced, max. voltage 20 Vpp (pre-EQ)
TUNER OUT: unbalanced, max. voltage 2 Vpp
SPEAKER OUT: speakon/1/4″ combo, 1/4″
OTHER
WEIGHT: 6.61 lbs / 3 Kg
WIDTH: 10.87 in. / 27.6 cm
DEPTH: 9.84 in. / 25 cm
HEIGHT: 3.27 in. / 8.3 cm
OUTPUT POWER: 800W RMS @ 4 ohms / 500W RMS @ 8 ohms
