Neck Material: Caramelized Maple
Neck Construction: Bolt-On with Graphite Reinforcement
Neck Finish: Hand-Rubbed Satin Urethane
Neck Shape: Speed Neck with Rolled Fingerboard Edges
Neck Binding: Rolled Fingerboard Edges
Scale Length: 25.5” (648mm)
Fingerboard Radius: Compound Radius (304.8mm to 406.4mm 12” - 16”)
Fingerboard Material: Caramelized Maple
Number of frets: 22
Fret Size: Jumbo
Nut Material: Graph Tech® TUSQ® XL
Nut Width: 1.6875” (42.86mm)
Position Inlays: 4mm Pearloid Dot
TrussRod Nut: Heel-mount Truss Rod Adjustment wheel
String trees: Fender® Standard String Guide
Headstock: Licensed Fender® Stratocaster®
Neck plate: 4-bolt Sculpted heel
Body Finish: Satin
Body Shape: Dinky
Body Material: Alder
Bridge: Gotoh Custom 510 Tremolo
Tuning Machines: Charvel®-Branded Die-Cast Locking
Control Knobs: Stratocaster®-Style Skirt
Switch Tip: Parchment
Bridge Pickup: Seymour Duncan® Custom Hot Rails® Strat® SHR-1B
Middle Pickup: Custom Seymour Duncan® Flat Strat® SSL-6 Single-Coil
Neck Pickup: Custom Seymour Duncan® Flat Strat® SSL-6 RWRP Single-Coil
Controls: Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone
Pickup Switching: 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Bridge Inner Coil and Middle Pickup, Position 3. Bridge Outer Coil and Neck Pickup, Position 4. Middle and Neck Pickup, Position 5. Full Neck Pickup
Pickup Configuration: SSS
